Why work with us?

  • Professional patent drawing services.
  • Quick turnaround.
  • Competitive pricing.
  • No outsourcing.  All drawings done in house by qualified professionals.
  • 8 years patent drawing experience.
  • Over 25 years of Mechanical Design and Illustration experience specializing in mechanical patents.
    Experts in 3D CAD programs.  We are able to utilize your clients CAD data to save time and ensure that the details are correct.

Pricing information

 With thousands of design and utility applications under our belt.  We  are able to provide fast efficient patent drawing services with a focus on your specific needs.  Adhering to the USPTO guidelines we can create documents that are produced in the most efficient way possible.  As and experienced 3d mechanical designer and patent illustration of complex mechanical devices I can handle the most technical cases.





Your clients may have 3d data in SolidWorks, Pro-E, or other CAD CAM software to assist them in the development of their product.  We use a modern approach to Patent art that will save time and provide the most accurate drawings possible.  We can also create patent drawings from photos or sketches as well.







We use your customers 3d data to create and efficient workflow.

We use your customers 3d data to create and efficient workflow.

experience makes the difference
